Nachfolgend findest du eine Zusammenstellung aller relevanten Beiträge, Builds und Videos, die auf meinem Blog bisher rund um das Thema NCASE M3 veröffentlicht wurden. Diese Übersicht dient dazu, dir einen vollständigen Einblick in die vielfältigen Aspekte dieses Gehäuses zu ermöglichen.
Technische Daten
| Variants | M3 Round, M3 Grater |
| Abmessungen (HxBxT) | 19.2 x 27.0 x 36.6 (without feet/protrusions/screws) 19.2 x 27.4 x 37.2 (including feet/protrusions/screws) |
| Volumen (l) | 18.97 (without feet/protrusions/screws) 19.57 (including feet/protrusions/screws) |
| Gewicht (kg) | 3-5kg based on the variant kit/bundle |
| PCIe Riser Support | Please refer to the M3 Builds For More Info Classic Config: Not Applicable Flipped Config: Not Applicable VGPU Config: PCIe X16 4.0 and 5.0 |
| Grafikkarte | Please refer to the M3 Builds For More Info M3-Round: Classic Config: 360mm long, 175mm tall, 4-Slots Flipped Config: 360mm long, 175mm tall, 4-Slots VGPU Config: 360mm long, 175mm tall, 4-Slots M3-Grater: Classic Config: 359mm long, 175mm tall, 4-Slots Flipped Config: 359mm long, 175mm tall, 4-Slots VGPU Config: 359mm long, 175mm tall, 4-Slots |
| CPU-Kühler | Please refer to the M3 Builds For More Info Classic Config: 168.5mm Flipped Config: 168.5mm VGPU Config: 70mm for 4-Slot graphics cards, 90mm for 3-Slot graphics cards |
| Wasserkühlung | Please refer to the M3 Builds For More Info 1 x 120 Radiator / AIO 1 x 140 Radiator / AIO 1 x 240 Radiator / AIO 1 x 280 Radiator / AIO based on components Note: The following Radiator/AIO combinations may be compatible with specific components. Please see M3 Builds for more information. – 2 x 240 Radiator / AIO – 2 x 280 Radiator / AIO – 3 x 240 Radiator / AIO – 3 x 280 Radiator / AIO |
| Motherboard | Please refer to the M3 Builds For More Info Mini-ITX, Deep-ITX, Mini-DTX, Micro-ATX |
| Netzteil | Please refer to the M3 Builds For More Info Classic Config: SFX, SFX-L, ATX (140mm) Flipped Config: same as Classic Config VGPU Config: SFX, SFX-L Note: ATX Power Supplies up to 160mm deep can fit with some Motherboards and 3-Slot Graphics cards. Please see M3 Builds for more information. |
| Festplatte | Please refer to the M3 Builds For More Info 3 x 2.5″ drives based on components 1 x 3.5″ drives based on components Note: Up to 12 x 2.5″ drives or 8 x 3.5″ drives can be accommodated with specific components. Please see M3 Builds for more information. |
| Lüfter | Please refer to the M3 Builds For More Info 3 x 120mm based on components 2 x 140mm + 1 x 120mm based on components 2 x 180mm + 1 x 120mm based on components Note: Up to 9 case fans (8 x 120mm + 1 x 92mm, or 6 x 140mm + 2 x 120mm + 1 x 92mm) can be installed simultaneously with specific components. Please see M3 Builds for more information. |
| Frontanschlüsse | Power Button 2x USB-A 1x USB-C Note: The M3-Grater variant does NOT include Front USB IO. |
| Material | Chassis: 2.5-18mm Aluminum, CNC Machined and Anodized Fan Bracket: 1.0mm Steel, Powder Coated Side Panels: 1.5mm Aluminum, Powder-Coated |
| Farben | Silber, Schwarz |
| Homepage | ncase.com |
| M3 Builds Page | M3 Builds |
| User-Manuel | User Manuals – NCASE |
NCASE 3 – Build I
soon…
Übersicht aller Artikel zum NCASE M2
Eine Übersicht aller von mir auf dem Blog behandelten Gehäuse findest du hier.
